Eye Tracker

Optional Features

The Eye Tracker package gives access to the EYETRACKER feature.

It is a feature used as a gateway between SCANeR and tracker systems.

The aim of the EYETRACKER module is to synchronize an eye tracker system with SCANeR studio simulation environment:

  • During the simulation: Trigger events depending of the driver gaze information and object looked (computed information can be retrieved into records).
  • Post-treatment: Get the tracker system outputs synchronized with all SCANeR studio simulation environment.
Key features
Main features
  • Time synchronization and data recording
  • Realtime monitoring
  • Eye tracker referential tuning
  • Gaze information in 3D and screen referential
  • Transport delay from communication to record less than 20ms
  • Compatible with ROI (region of interest) information from Eye tracking product
  • Know what the driver is looking at (the road ahead, a particular traffic light, the speedometer, any of the mirrors or an item of in vehicle equipment, etc.)
  • Create SCANeR script reacting to eye tracker (pedestrian cross the road when the driver is looking at the in-vehicle communication system, etc.)
  • Compatibility with SCANeR VIDEO to record the Eye tracking stream (if available)
  • Compatibility with the optional SCANeR Head tracker package if the eye tracker device does not embed its own (NAC, Pertech, etc.)
  •
Included simulation modules
  • EYETRACKER
Supported hardware
  • Smarteye pro from 4.5 to 8.2.2
  • SMI from 1.5 to 2.0
  • Communication UDP

Note: If your hardware is not into the list, please do not hesitate to contact our service for further information (it may have been added recently following an evolution). Otherwise, it is always possible to ask to AVSimulation for a service or, using the Studio SDK, interface and synchronize any external device.
